JOULLE 17-001 line drawing
DrawingJOULLE 17-001
Dimensions (in)
W112 1/8
D2.5
H17 1/2
Max drop72

112 1/8 W × 2.5 D × 17 1/2 H in · max drop 72 in

Not to scale

Lake + Wells · JOULLE 17-001
