JUNIP 27-001 line drawing
DrawingJUNIP 27-001
Dimensions (in)
W31 15/16
D31 15/16
H76 7/16
Max drop90

31 15/16 W × 31 15/16 D × 76 7/16 H in · max drop 90 in

Not to scale

Lake + Wells · JUNIP 27-001
