JUNIP 09-001 line drawing
DrawingJUNIP 09-001
Dimensions (in)
W64 15/16
D20 15/16
H15 15/16
Max drop110

64 15/16 W × 20 15/16 D × 15 15/16 H in · max drop 110 in

Not to scale

Lake + Wells · JUNIP 09-001

More from the JUNIP Edition

View all layouts
JUNIP 11-001 drawingJUNIP 11-00142 15/16 W × 42 15/16 D × 54 7/16 H inJUNIP 14-001 drawingJUNIP 14-00131 15/16 W × 4.5 D × 76 7/16 H inJUNIP 15-001 drawingJUNIP 15-00142 15/16 W × 42 15/16 D × 48 15/16 H inJUNIP 21-001 drawingJUNIP 21-00164 15/16 W × 42 15/16 D × 65 7/16 H inJUNIP 26-001 drawingJUNIP 26-00162 7/8 W × 47 3/8 D × 32 1/2 H inJUNIP 27-001 drawingJUNIP 27-00131 15/16 W × 31 15/16 D × 76 7/16 H in
