JUNIP 05-002 line drawing
DrawingJUNIP 05-002
Dimensions (in)
W64 15/16
D4.5
H15 15/16
Max drop110

64 15/16 W × 4.5 D × 15 15/16 H in · max drop 110 in

Not to scale

Lake + Wells · JUNIP 05-002
