JUNIP 04-004 line drawing
DrawingJUNIP 04-004
Dimensions (in)
W20 15/16
D20 15/16
H46 1/2
Max drop110

20 15/16 W × 20 15/16 D × 46 1/2 H in · max drop 110 in

Not to scale

Lake + Wells · JUNIP 04-004
