JUNIP 01-001 line drawing
DrawingJUNIP 01-001
Dimensions (in)
Dia.5
H10 7/16
Max drop110

Ø5 × 10 7/16 H in · max drop 110 in

Not to scale

Lake + Wells · JUNIP 01-001

More from the JUNIP Edition

View all layouts
JUNIP 02-001 drawingJUNIP 02-00120 15/16 W × 4.5 D × 24 1/2 H inJUNIP 03-001 drawingJUNIP 03-00120 15/16 W × 4.5 D × 21 7/16 H inJUNIP 03-002 drawingJUNIP 03-00225 9/16 W × 4.5 D × 34 1/2 H inJUNIP 04-001 drawingJUNIP 04-00131 15/16 W × 4.5 D × 21 7/16 H inJUNIP 04-002 drawingJUNIP 04-00242 15/16 W × 4.5 D × 21 7/16 H inJUNIP 04-003 drawingJUNIP 04-00320 15/16 W × 20 15/16 D × 13 1/2 H in
